The best cabinet pull-out hardware

Check whether you need a bucket before you price a whole kit. The container cracks at the handle cut-out long before the frame or the slides wear out.

By Ryder M. · Last reviewed September 27, 2026

Cabinet hardware and drawer slides with tools

Lid & Liner is reader-supported. If you buy through a link on this page we may earn a commission at no extra cost to you. It never changes which product we rank first — how we pick and how we make money.

Start with the cheapest possibility

If your pull-out has stopped being pleasant to use, work out which part failed before you price a replacement. A cracked bucket is a part. A binding drawer is usually an adjustment. Only a stripped slide is a kit.

#ProductBest forPrice
01
Bottom-mount pull-out waste bins on soft-close slides
Rev-A-Shelf 4WCSC-1835DM-2 Bottom-Mount Double, 2 x 35 QuartThe version fitted with real Blum Blumotion heavy-duty slides — the same hardware that goes into high-end cabinetry.
Best slides
02
Replacement plastic waste containers for a pull-out frame
Rev-A-Shelf RV-35-52 Replacement Pull-Out Containers, 35 QuartReplacement 35-quart buckets, because a cracked bin is not a reason to rip out a working frame.
Best repair part
03
Steel-framed double pull-out waste container for a cabinet
Rev-A-Shelf 53WC-1835SCDM-217 Double Pull-Out, 35 QuartTwo 35-quart buckets on a steel frame with soft-close slides, and a door-mount kit so the cabinet door pulls it out.
Best steel-frame double
04
Wire-frame double pull-out trash can kit for a cabinet
Rev-A-Shelf RV-18PSC-18-5 Soft-Close Double Pull-Out, 35 QuartThe common-as-dirt RV-series kit: two 35-quart bins on a bottom-mount soft-close frame, stocked by every major retailer.
Best value double
05
Pull-out trash and recycling bins inside a kitchen cabinet
simplehuman 35L Dual Compartment Under-Counter Pull-Out CanThe pull-out that is easiest to install and hardest to break: an all-steel frame on commercial ball-bearing tracks that arrive as one pre-assembled piece.
Best pull-out overall

How we picked

  • Slide quality above everything. Two loaded buckets through thousands of cycles is a real load, and the slides carry all of it. Genuine Blum Blumotion is the benchmark and it is serviceable.
  • Frame rigidity. A wire frame flexes under load and that flex is what walks slides out of alignment. A steel-panel frame does not.
  • Mounting method. Door mount is better day to day, bottom mount is more forgiving at install.
  • Whether spares exist. A system with replacement buckets available is a system you can keep for a decade.
  • Published minimum opening. The brands that state one save you a return.

Methodology · disclosure.

The hardware in full

Bottom-mount pull-out waste bins on soft-close slides

01 — Best slides

Rev-A-Shelf 4WCSC-1835DM-2 Bottom-Mount Double, 2 x 35 Quart

The version fitted with real Blum Blumotion heavy-duty slides — the same hardware that goes into high-end cabinetry.

Capacity
2 x 35 quart
Slides
Blum Blumotion heavy-duty soft close
Mounting
Bottom mount
Minimum opening
15" W x 20-5/8" H

Slides are where pull-out bins fail, because they carry a lot of weight through a lot of cycles. Blum's Blumotion is the benchmark: heavy-duty, genuinely soft-closing, and serviceable. If you are installing this in a kitchen you intend to keep, this is the version to buy.

What we'd flag: the minimum cabinet opening is 15" wide by 20-5/8" high, which rules out a lot of 12-inch cabinets. Check the opening, not the cabinet's nominal size.

Replacement plastic waste containers for a pull-out frame

02 — Best repair part

Rev-A-Shelf RV-35-52 Replacement Pull-Out Containers, 35 Quart

Replacement 35-quart buckets, because a cracked bin is not a reason to rip out a working frame.

Capacity
35 quart each
Fits
Rev-A-Shelf RV-series frames
Material
Plastic

The bucket cracks long before the frame or the slides wear out — usually at the handle cut-out. Replacement containers cost a small fraction of a whole kit and drop straight into an existing RV-series frame. This is the first thing to check before you price a replacement.

What we'd flag: confirm your frame is an RV-series before ordering. Other Rev-A-Shelf lines take different buckets, and the dimensions are close enough to be misleading.

Steel-framed double pull-out waste container for a cabinet

03 — Best steel-frame double

Rev-A-Shelf 53WC-1835SCDM-217 Double Pull-Out, 35 Quart

Two 35-quart buckets on a steel frame with soft-close slides, and a door-mount kit so the cabinet door pulls it out.

Capacity
2 x 35 quart
Slides
Soft close
Mounting
Door mount
Frame
Steel

Door mounting is the detail that separates a good pull-out from an annoying one: you pull the cabinet door and the bins come with it, rather than opening a door and then pulling a separate frame. The steel frame will not flex under two full buckets the way a wire basket does.

What we'd flag: door-mount kits have to be adjusted carefully at install or the door sits proud of the run. Budget the extra fifteen minutes to get the brackets square.

Wire-frame double pull-out trash can kit for a cabinet

04 — Best value double

Rev-A-Shelf RV-18PSC-18-5 Soft-Close Double Pull-Out, 35 Quart

The common-as-dirt RV-series kit: two 35-quart bins on a bottom-mount soft-close frame, stocked by every major retailer.

Capacity
2 x 35 quart
Slides
Soft close, bottom mount
Cabinet
Standard 18-inch
Replacement bins
Sold separately

There is a reason this is the one most kitchen fitters reach for — it fits standard 18-inch cabinets, the parts are widely stocked, and replacement containers are sold separately so a cracked bucket does not mean a new kit.

What we'd flag: a wire frame flexes under two full buckets in a way a steel-panel frame does not. Over years, that flex is what knocks the slides out of alignment.

Pull-out trash and recycling bins inside a kitchen cabinet

05 — Best pull-out overall

simplehuman 35L Dual Compartment Under-Counter Pull-Out Can

The pull-out that is easiest to install and hardest to break: an all-steel frame on commercial ball-bearing tracks that arrive as one pre-assembled piece.

Capacity
35 liters / 9.3 gallons, two buckets
Minimum opening
20" H x 10" W x 20" D
Tracks
Commercial-grade ball bearing, pre-assembled one-piece
Extension
Up to 3 feet
Liner codes
Codes G and D
Frame
All steel

Most pull-out kits arrive as a bag of brackets and a diagram. This one comes as a single pre-assembled track, which turns a two-hour job into a twenty-minute one and removes the misalignment that causes a pull-out to bind six months later. The tracks are commercial-grade ball-bearing and extend up to three feet, so the back bucket comes fully clear of the cabinet.

What we'd flag: the minimum cabinet opening is 20" high x 10" wide x 20" deep, and plenty of older sink cabinets fail the depth test because of the trap. Measure to the back wall, past the plumbing, before you order.

Diagnose it before you buy

SymptomLikely causeWhat you need
The bucket has cracked at the handleNormal fatigue — the usual failureA replacement bucket
The drawer binds part way outSlides out of alignment, often from frame flexAdjustment first, then possibly slides
It closes with a bangThe soft-close damper has failedA replacement slide pair
The door sits proud of the cabinet runA door-mount bracket needs adjustingTen minutes with a screwdriver
The whole frame rocksFixings have loosened into the cabinet floorTighten, or move to fresh screw positions
A slide has visible damage or lost bearingsOverloading, or years of misalignmentNew slides, or a new kit

Two of those six are a screwdriver and one is a cheap part, which is why it is worth diagnosing rather than assuming. The one genuinely terminal case is a damaged slide on a wire-frame kit, where the slide is often not sold separately and a new kit costs little more.

Identifying what you already have

This matters because buckets are not interchangeable between lines. Three things to look at.

  1. Pull the unit fully out and look for a molded part number on the bucket itself, usually on the base or inside the rim. Rev-A-Shelf's RV-series buckets carry an RV code.
  2. Look at the frame. A wire basket frame is the RV series. A folded steel panel frame is the 53WC series. A wood and steel carcass with Blum slides is the 4WCSC series.
  3. Measure the bucket. Thirty-five quarts is the most common domestic size and 50 quarts exists for larger cabinets. Measure rather than assuming — a 35 and a 50 look more similar than they are.

If it is a simplehuman under-counter unit rather than a Rev-A-Shelf, the buckets are proprietary and go by simplehuman's own part scheme, and the liners go by code letter — Codes G and D on the 35-liter dual.

Fitting it so it lasts

  1. Step 01

    Measure the clear opening, not the cabinet

    Width, height and depth to the nearest obstruction — under a sink that is the trap, not the back wall. The 4WCSC needs 15" W x 20-5/8" H; simplehuman's 35L dual needs 20" H x 10" W x 20" D. Full measuring guide.

  2. Step 02

    Check the cabinet floor is sound

    The whole load goes through screws into the cabinet base. Particleboard that has been wet under a leaking trap will not hold, and that is extremely common in sink cabinets. Fix or reinforce it first — a pull-out fitted to soft board will work loose within a year.

  3. Step 03

    Get the frame square before you tighten anything

    Dry-fit, check it is square to the opening and level front to back, and only then drive the screws home. Misalignment at install is the cause of most binding six months later, and it is much harder to correct afterwards.

  4. Step 04

    Adjust the door bracket last, and patiently

    On a door-mount unit the bracket position sets where the door sits relative to the rest of the run. Expect to adjust it two or three times to get the gap even. Budget the extra fifteen minutes rather than living with a proud door.

  5. Step 05

    Re-tighten everything after six months

    Fixings settle and loosen with use. Ten minutes with a screwdriver at the six-month mark genuinely extends the life of the slides, because a loose frame is what starts the misalignment cycle.

Common questions

Can you buy replacement buckets for a pull-out trash can?

Yes. Rev-A-Shelf sells RV-series containers separately for a fraction of a whole kit, and the bucket is what usually cracks. Confirm your frame is an RV-series first — other lines take different buckets.

What are the best slides for a pull-out trash can?

Blum Blumotion heavy-duty soft-close, which is the hardware used in high-end cabinetry and is serviceable. Rev-A-Shelf's 4WCSC series is fitted with them.

Why does my pull-out trash drawer stick?

Usually the slides have come out of alignment, most often because a wire frame has flexed under two loaded buckets or the fixings have loosened. Tighten and re-square before assuming the slides are finished.

How do I know which Rev-A-Shelf model I have?

Look for a molded part number on the bucket, then at the frame: a wire basket is the RV series, a folded steel panel is 53WC, and a wood-and-steel carcass with Blum slides is 4WCSC.

Is door mount or bottom mount better?

Door mount is better to live with — the cabinet door pulls the bins out with it, so one action instead of two. Bottom mount is more forgiving to install because there is no door bracket to align.

Can I fit a pull-out to a cabinet with a damaged floor?

Not reliably. The whole load goes through screws into the base, and water-damaged particleboard under a leaking trap will not hold. Repair or reinforce the floor first — this is very common in sink cabinets.

Sources

Every specification on this page traces to one of these, checked at the time of writing. Where a manufacturer does not publish a figure, the page says so rather than estimating it.
